1805MHz-1880MHz 8W Final Solution

應用方案 | 日期：2021-09-23 | 閱讀：

Final:

DXG1PH19A-60N

Package Type: DFN 7×6.5mm

	CW Pulsed 10%	Modulated Signal
Freq (MHz)	Psat (dBm)	Gp (dB)@40.3dBm	DE (%)@40.3dBm	ACLR (dBc)@40.3dBm
1805	48.2	18.3	61.8	-33.2
1842	48.2	18.4	61.8	-31.4
1880	48.2	18.3	62.0	-30.0
Remark : Test Condition CW Pulsed: 10% Duty Cycle, 100uS Duration; Modulated Signal Type: 3.84MHz, 1C_WCDMA, PAR=7.8dB; 64DPCH; Tested without isolator;
